This section contains the following subsections which describe how to make a
measurement and how to use markers, math functions, filters, analysis tools,
quick actions, and digital channels.
• “Making a Measurement on a Waveform”
• “Using Markers”
• “Using Math Functions and Filters”
• “Using Analysis
Tools”
• “Using Quick Actions”
• “Controlling Digital Channels”
Figure 2-4 Screen Image of the CX3300 Application
Position indicator
Mode tab
Timebase position
Tool Palette
Trigger level indicator
Offset/Null indicator
Data view
Graph view
Analysis view
Main Waveform
Timebase
position indicator
Timebase
reference indicator
Run control
Trash bin
Waveform tray
