Keysight Signal Generators Programming Guide 175
Programming the Status Register System
Accessing Status Register Information
Table 4-2 Effects of :STATus:PRESet
Register
a
a
Table reflects :STAT:PRES values for an E4438C with options 001, 002, 601, or 602 and UN7. To determine the registers that apply to your
signal generator, refer to
Figure 4-1 on page 164 through Figure 4-6 on page 169 and Table 4-4 on page 178 through
Table 4-18 on page 210.
Value after
:STATus:PRESet
:STATus:OPERation:ENABle 0
:STATus:OPERation:NTRansition 0
:STATus:OPERation:PTRransition 32767
:STATus:OPERation:BASeband:ENABle 0
:STATus:OPERation:BASeband:NTRansition 0
:STATus:OPERation:BASeband:PTRransition 32767
:STATus:QUEStionable:CALibration:ENABle 32767
:STATus:QUEStionable:CALibration:NTRansition 32767
:STATus:QUEStionable:CALibration:PTRansition 32767
:STATus:QUEStionable:ENABle 0
:STATus:QUEStionable:NTRansition 0
:STATus:QUEStionable:PTRansition 32767
:STATus:QUEStionable:FREQuency:ENABle 32767
:STATus:QUEStionable:FREQuency:NTRansition 32767
:STATus:QUEStionable:FREQuency:PTRansition 32767
:STATus:QUEStionable:MODulation:ENABle 32767
:STATus:QUEStionable:MODulation:NTRansition 32767
:STATus:QUEStionable:MODulation:PTRansition 32767
:STATus:QUEStionable:POWer:ENABle 32767
:STATus:QUEStionable:POWer:NTRansition 32767
:STATus:QUEStionable:POWer:PTRansition 32767
:STATus:QUEStionable:BERT:ENABle 32767
:STATus:QUEStionable:BERT:NTRansition 32767
:STATus:QUEStionable:BERT:PTRansition 32767
Table 4-3 Effects of :STATus:PRESet
Register Value after
:STATus:PRESet
:STATus:OPERation:ENABle 0
:STATus:OPERation:NTRansition 0
:STATus:OPERation:PTRransition 32767
:STATus:QUEStionable:CALibration:ENABle 32767
:STATus:QUEStionable:CALibration:NTRansition 32767
:STATus:QUEStionable:CALibration:PTRansition 32767
:STATus:QUEStionable:ENABle 0
