Keysight Signal Generators Programming Guide 69
Using IO Interfaces
Using USB (Keysight MXG)
Using USB (Keysight MXG)
CAUTION USB cables are not industrial graded and potentially allows data loss in noisy
environments.
USB cables do not have a latching mechanism and the cables can be pulled out of the
PC or instrument relatively easily.
The maximum length for USB cables is 30 m, including the use of inline repeaters.
NOTE The USB interface is available only on the Keysight MXG signal generator.
The Keysight MXG’s USB 2.0 interface supports USBTMC or USBTMC–USB488 specifications.
For more information on connecting instruments to the USB, refer to the Keysight
Connection Expert in the Keysight IO Libraries Help.
USB 2.0 connectors can be used to communicate with the signal generator. The
N5161A/62A/81A/82A is equipped with a Mini–B 5 pin rear panel connector (device USB). Use a
Type–A to Mini–USB 5 pin cable to connect the signal generator to the computer (Refer to “Setting
Up the USB Interface” on page 70). Connect the Type–A front panel connector (host USB) can be used
to connect a mouse, a keyboard, or a USB 1.1/2.0 flash drive (USB media). (Refer to the User’s
Guide.) ARB waveform encryption of proprietary information is supported. Many functions provided
by GPIB, including GET, non–SCPI remote languages, and remote mode are available using the USB
interface.
NOTE For a list of compatible flash drives to use with the USB external interface. Refer to
http://www.keysight.com/find/mxg.
Do not use the Type A front panel USB to connect to a computer.
The following sections contain information on selecting and connecting I/O libraries and the USB
interface that are required to remotely program the signal generator through the computer and
combining those choices with one of several possible USB interface protocols.
• “Selecting I/O Libraries for USB” on page 70
• “Setting Up the USB Interface” on page 70
• “Verifying USB Functionality” on page 71
