Keysight Signal Generators Programming Guide 199
Programming the Status Register System
Status Groups
Data Questionable Frequency Condition Register
The Data Questionable Frequency Condition Register continuously monitors the hardware and
firmware status of the signal generator. Condition registers are read- only.
Table 4-13 Data Questionable Frequency Condition Register Bits
Bit Description
0 Synth. Unlocked. A 1 in this bit position indicates that the synthesizer is unlocked.
1 10 MHz Ref Unlocked. A 1 in this bit position indicates that the 10 MHz reference signal is unlocked.
2
a
a
In the N5161A/81A and N5162A/82A these bits are always set to 0.
1 GHz Ref Unlocked. A 1 in this bit position indicates that the 1 GHz reference signal is unlocked.
3
b
b
In the N5161A/62A/81A/82A/83A, E4428C, E8257D, E8663B, and the E8663D, this bit is always set to 0.
Baseband 1 Unlocked. A 1 in this bit position indicates that the baseband generator is unlocked.
4 Unused. This bit is always set to 0.
5
b
Sampler Loop Unlocked. A 1 in this bit position indicates that the sampler loop is unlocked.
6
b
YO Loop Unlocked. A 1 in this bit position indicates that the YO loop is unlocked.
7−14 Unused. These bits are always set to 0.
15 Always 0.
Table 4-14 Data Questionable Frequency Condition Register Bits
Bit Description
0 Synth. Unlocked. A 1 in this bit position indicates that the synthesizer is unlocked.
1 10 MHz Ref Unlocked. A 1 in this bit position indicates that the 10 MHz reference signal is unlocked.
2 1 GHz Ref Unlocked. A 1 in this bit position indicates that the 1 GHz reference signal is unlocked.
3 Unused. This bit is always set to 0.
4 Unused. This bit is always set to 0.
5 Sampler Loop Unlocked. A 1 in this bit position indicates that the sampler loop is unlocked.
6–14 Unused. These bits are always set to 0.
15 Always 0.
Query: STATus:QUEStionable:FREQuency:CONDition?
Response: The decimal sum of the bits set to 1.
