Keysight Infiniium 8000 Series - Page 146

Chapter 7: Replaceable Parts
Replaceable Parts List
146
W18 8120-1703 1 CABLE-POWER (Option 900-UK)
W18 8120-0696 1 CABLE-POWER (Option 901-AUSTL)
W18 8120-1692 1 CABLE-POWER (Option 902-EUR)
W18 8120-2296 1 CABLE-POWER (Option 906-SWIT)
W18 8120-2957 1 CABLE-POWER (Option 912-DEN)
W18 8120-4600 1 CABLE-POWER (Option 917-AFRICA)
W18 8120-4754 1 CABLE-POWER (Option 918-JAPAN)
W18 8120-6799 1 CABLE-POWER (Option 919-ISRAEL)
W18 8120-6871 1 CABLE-POWER (Option 920-ARGENTINA)
W18 8120-6979 1 CABLE-POWER (Option 921-CHILE)
W18 8120-8377 1 CABLE-POWER (Option 922)
W18 8120-8871 1 CABLE-POWER (Option 927-THAILAND)
Electrical Assemblies
A2 D8064-62601 1 POWER SUPPLY SUBASSEMBLY
A5 0950-4635 1 INVERTER BOARD
A13 2090-0911 1 LCD XGA DISPLAY
MP46 54858-66513 1 USB TOUCHSCREEN CONTROLLER BOARD, PROGRAMMED
A22 54857-61201 1 CAL BRACKET SUBASSEMBLY
PC Motherboard
A4 0960-2522 1 CONVERTER CARD-ATAPI TO SATA
A6 0950-4741 1 CD ROM Drive
A8 1 HARD DISK DRIVE with SOFTWARE (NOT ON OPTION 017 REMOVABLE
DRIVE)
DSO/MSO8000A (with Intel motherboard): Part number D81004-68701
DSO/MSO8000A (with ADLINK motherboard): Part number D81004-68702
5483xA/D, 5485xA: Part number 54855-68704
Replace A19 motherboard with same type.
A19 D81004-68703 1 MOTHERBOARD SUBASSEMBLY (Includes new deck and heat sink.)
A19 D81004-68809 1 MOTHERBOARD SUBASSEMBLY
A19 D8104-68700 1 MOTHERBOARD SUBASSEMBLY
All Configurations
A9 54810-66506 1 PROBE INTERFACE BOARD
A12 0960-2530 1 DISPLAY BOARD (installed only with Intel motherboard)
A16 54832-68703
0
4-CH REPLACEMENT I/O KIT (DSO models)
A16 54838-68703
0
4-CH REPLACEMENT I/O KIT (MSO models)
A17 54826-66507 1 KEYBOARD - CURSOR
A18 54832-66504 1 KEYBOARD - 4CH (DSO models)
A18 54826-66504 1 KEYBOARD - 4CH (MSO models)
A20 D8064-66401
1
FAN CONTROLLER BOARD
A21 54855-66515
1
INTERFACE & GPIB BOARD
Fans
B1 3160-4134 6 12 V FAN
Internal Chassis Parts
H1 0515-2219 3 SCREW-MACH; M2.5 X 0.45 5MM-LG ; T8
H2 54503-25701 4 HEX NUT BNC
H3 0515-1025 3 SCREW-MACH; M3 X 0.5 26MM-LG; T10; WASHER
H4 0515-1410 4 SCREW-MACH; M3 X 0.5 20MM-LG; T10; PAN; WASHER
H5 0515-0430 13 SCREW-MACH; M3 X 0.5 6MM-LG; T10; PAN; WASHER
Replaceable Parts
Ref.
Des.
Keysight Part
Number Qty Description
