Chapter 5: Troubleshooting
To setup the BIOS
91
To setup the BIOS
If the BIOS settings become corrupt, the Infiniium oscilloscope PC motherboard will
not recognize the hard drive and the unit may not boot. The motherboard BIOS setup
procedure is presented in the following pages.
Configure the Motherboard BIOS parameters.
Use this procedure to set the motherboard BIOS.
1
Connect the power cable to the Infiniium oscilloscope.
2 Connect the external keyboard to the rear panel.
3 Press the delete key when you see the following prompt on the bottom of the
screen
Press TAB to Show POST screen, DEL to enter SETUP, F12 to select boot device.
Note: If you do not see the prompt, or the oscilloscope does not appear to be functioning,
check the ribbon cable connectors. Otherwise, continue with the next step.
4
Go to Load Optimized Defaults (systems with the Intel motherboard) or
go to Load 8.4” LCD Defaults (systems with the ADLINK motherboard) and
press Enter key. Select Y to load the defaults, then press the Enter key.
5 Press F10 to save and exit the setup. Type “Y” to save changes.
