8000 Series Oscilloscope Back Panel
Note: Your instrument’s back panel configuration may differ from this diagram.
LAN
Port
GPIB Interface
Mouse
and
Keyboard
Ports
Video
Output
CD-ROM
Drive
USB
Ports
Line In
Line Out
Microphone
TTL
Trig
Out
AC Power
Input
Aux
Trig
In
Aux
Out
Parallel
Printer
Port
RS232
COM
Port
Rear Foot
Kensington
Equipment
Lock
Optional Removable
Hard Drive
