Setting Up the Oscilloscope 1
Keysight Infiniium S-Series Oscilloscopes User’s Guide 19
Turning On the Oscilloscope
• Press the power switch in the lower left corner of the oscilloscope front panel.
After a short initialization period, the oscilloscope display appears. The
oscilloscope is ready to use.
• You can connect and disconnect probes and cables while the oscilloscope is
turned on.
Changing the Administrator Password
On Keysight Infiniium real-time oscilloscopes with the Windows 10 operating
system, the default Administator user account password is "Keysight". Change the
Administrator password to something more secure (and less well-known).
Figure 5 Turning On the oscilloscope
Push
for Vernier
Push
to Zero
DIGITAL D15-D0
1
2
3
4
All Inputs
1M Ω ±40V MAX
50
5V MAX
1M
~
~
14pF
Probe Comp
+
3
4
Power switch
