Using the Oscilloscope 2
Keysight Infiniium S-Series Oscilloscopes User’s Guide 33
Using the Setup and Display Controls
With the setup and display controls you can quickly get a stable waveform display,
enable or disable the touch screen, clear the display, and set the oscilloscope to a
known starting condition.
Using Auto Scale and Default Setup
To automatically configure the oscilloscope to best display the current input
signal(s), press [Auto Scale] or choose Control > Autoscale.
To reset the oscilloscope to its default setup, press [Default Setup]. You can use the
Undo button to undo a default setup.
Using the Touch Screen
1 To enable the touch screen so it responds to multi-touch gestures, similar to
those used on tablets and smart phones, press [Touch] or choose Utilities > User
Preferences... and select the Enable Touch Screen check box.
2 Touch the drag waveform icon to highlight it.
Now you can use gestures to flick items horizontally, drag a waveform vertically,
drag horizontally to change the horizontal delay, pinch horizontally to adjust
time/div and delay settings, pinch vertically to adjust a waveform’s V/div and
offset settings, or tap to select waveforms and other selections on the display.
Clearing the Waveform Display
When you press [Clear Display] or click , the oscilloscope clears acquired
waveform data from the display in preparation for another acquisition. If the
oscilloscope is in Run mode and is receiving triggers, it will update the display as it
collects new waveform data.
Clearing the waveform display also resets averaging, infinite persistence, color
grade persistence, histograms, and the mask testing database.
Figure 11 Setup and display control keys
Auto
Scale
Default
Setup
Clear
Display
Touch
NOTE
Save the Current Oscilloscope Configuration
Before using the default setup, you may want to save the current oscilloscope configuration
for later use. See the online help (described in chapter 3) for instructions on saving setups,
and for information on the exact configuration that is set when you use the default setup.
