Keysight InfiniiVision 1200 X Series User Manual

4 Keysight InfiniiVision 1200 X-Series and EDUX1052A/G Oscilloscopes User's Guide
Figure 2 InfiniiVision 1200 X-Series 2-Channel Oscilloscope
Mixed Signal Oscilloscope
MSOX1204G
Digital Storage Oscilloscope
DSOX1202G
200 MHz 2 GSa/s70 MHz 2 GSa/s
InfiniiVision
Push
Fine
Push
Zero
Push to
Select
Force
Entry
Horizontal
Leve-l
Measure
Vertical
Intensity
Push
for Fine
Push
to Zero
Tr i g g e r
Push for 50%
Push to Select
Tr i g g e r
FFT
External
Math
Default
Setup
Run
Stop
Single
Wave
Gen
Acquire
2
1
CursorsMeas
Utility
Analyze
Display
Save
to USB
Help
Save
Recall
Auto
Scale
Back
Quick
Action
Demo
Probe
Comp
Ext
Tr i g
Gen
Out
Inputs
CH1 and CH2
150V RMS
Input
Ext Trig
30V RMS
~
1M
~
16pF
Demo
Probe
Comp
1
2
Table 1 InfiniiVision 1200 X-Series and EDUX1052A/G Oscilloscopes Model Numbers, Bandwidths
Model: EDUX1052A EDUX1052G DSOX1202A DSOX1202G DSOX1204A DSOX1204G
Channels: 2 4
Bandwidth: 50 MHz 70 MHz
Bandwidth upgrades: 70 MHz to 100 MHz with
D1202BW1A upgrade
70 MHz to 100 MHz with
D1200BW1A upgrade
70 MHz to 200 MHz with
D1202BW2A upgrade
70 MHz to 200 MHz with
D1200BW2A upgrade
100 MHz to 200 MHz with
D1202BW3A upgrade
100 MHz to 200 MHz with
D1200BW3A upgrade
Sampling rate: 1 GSa/s 2 GSa/s (interleaved), 1 GSa/s (non-interleaved)
Memory: 200 kpts 2 Mpts (1 Mpts when the
External Trig channel is on)
2 Mpts (interleaved), 1 Mpts
(non-interleaved)
Segmented memory: No Yes
