Keysight N9041B - Meas Preset; 3.11.8.2 Advanced; IF Gain

3 VMA Mode
3.11 Phase and Amplitude vs Time Measurement
Harmonics (SA Mode only)
Parameters affected by Auto Couple are:
–
Resolution Bandwidth
–
Fundamental Frequency
–
Dwell Time
–
Range Table Resolution Bandwidths
–
Range Table Dwell Times
Meas Preset
Restores all the measurement parameters to their default values.
Remote
Command
:CONFigure:PAVTime
Example
:CONF:PAVT
Couplings Selecting Meas Preset restores all measurement parameters to their default values
3.11.8.2 Advanced
Contains controls for setting advanced functions of the instrument.
IF Gain
Sets the IF Gain function to Auto, Low Gain or High Gain. These settings affect
sensitivity and IF overloads.
Remote Command
[:SENSe]:PAVTime:IF:GAIN[:STATe] ON | OFF | 1 | 0
[:SENSe]:PAVTime:IF:GAIN[:STATe]?
[:SENSe]:PAVTime:IF:GAIN:AUTO[:STATe] ON | OFF | 1 | 0
[:SENSe]:PAVTime:IF:GAIN:AUTO[:STATe]?
Example
:PAVT:IF:GAIN ON
:PAVT:IF:GAIN?
:PAVT:IF:GAIN:AUTO ON
:PAVT:IF:GAIN:AUTO?
Notes ON = high gain
OFF = low gain
1827 Vector Modulation Analyzer Mode User's &Programmer's Reference
