• At the top of the Process Window screen is a field to enter your Process Window Name.
• After entering the name click on the Green Checkmark button. The software will ask you if you
want to save this new Process Window.
• Click on Yes.
4. Run a Profile button
• Enter in your product name or choose an existing one from the drop down list.
• Choose your Process Window (this was created in the previous step).
• Name your oven or choose an existing one from the drop down list. (If you are running on a
KIC 2000 compatible oven controller computer this was already done in the Global Preferences).
• Click the Forward Arrow button and follow the instructions on each screen.
• At the Select Thermocouples to Use screen click on the TC’s you have attached to the board and
plugged into your KIC Profiler.
• Make sure TC 1 is the Air TC and is extended 1 inch in front of the leading edge of the
board.
• Click the Start Profile (Green Traffic Light) button.
• Once you have placed the KIC Profiler and board in the oven and run the profile the KIC Profiler
Transmit models will automatically retransmit all the data when it drops below the profile stop
temperature as it exits. For the Data log models you must reconnect the download cable.
• The profile will be displayed and you can analyze and predict to optimize it, or if you have the
Navigator option the software will optimize the profile and oven setup automatically. Upon
exiting the Graph screen you can choose to run another profile with the original or predicted set
points and conveyor speed.
Once you have set your Global Preferences and Process Windows you do not need to do these steps for
every profile. You can just do Steps 1 & 4, and skip 2 and 3.
