SRA Smart Reflow Analyzer Hardware Guide SRA-330200-000
17
Safe Handling after Exiting the Oven
As the SRA emerges from the oven, the pallet and shield will be hot to the touch. Your kit includes a pair of safety
gloves, and it is absolutely required that you use these gloves for handling the unit after an oven run.
The safety gloves provided with your kit feature a fabric construction that is rated to permit holding an object heated
to 120°C (250°F) for up to 30 seconds. Operators should never hold the device longer than 30 seconds and should
only hold it as long as needed to move it safely to a workbench or other appropriate flat surface.
Caution: Never substitute gloves that are not rated for similar temperature and holding cycle specifications.
Contact your device manufacturer for replacement or extra pairs.
Safely Remove the SRA from the Oven
Hot Surface: Wear the safety gloves supplied
with your kit during this procedure.
1. As the SRA reaches the end of the conveyor, the
handle at the front of the device can be used to lift it
from the conveyor.
2. Carry the SRA away from the oven area, and place on a flat, level surface that is unaffected by the unit’s
3. Follow the procedure titled Safely Opening the Shield.
