Safely Opening the Shield
Hot Surface: Wear the safety gloves
supplied with your kit during this
procedure.
1. Carefully pull up on the latch to open the
shield.
2. With a datalogger model, connect the USB
download cable to the SRA module to
download the data.
Note: On Wi-Fi enabled versions, it is not
necessary to connect the USB cable to the
SRA module as the data is wirelessly
downloaded via the Smart Dock.
3. It is recommended to place the SRA in front of a fan or other cooling station arrangement to aid in the cooling
process.
