SRA Smart Reflow Analyzer Hardware Guide SRA-330200-000
3
SRA Hardware Initialization
To begin profiling in either datalog or Wi-Fi mode, you must first set up your SRA for use on your PC. Both modes
communicate to the computer through a standard USB port ā datalog mode uses a cable, Transmitter (Wi-Fi) mode
uses the Smart Dock. If the computer has no available USB ports, use a standard 2-8 port hub to add an open port.
Note: Install Profiling Software 2G BEFORE connecting the SRA Smart hardware to the computer.
Connecting the hardware before the software is installed may result in Windows OS selecting the
incorrect driver for the device and it will not connect to the software.
The normal setup routine must follow the sequence shown below:
1. Install the software.
2. Install the USB security dongle.
3. Connect the SRA Smart Reflow Analyzer hardware to the computer.
Note: When connecting the SRA Smart Reflow Analyzer to laptop computers that utilize a floating
ground connection (2-prong power plug) manually ground the laptop before connecting the SRA. This
procedure will prevent unwanted electrical interference that may distort the temperature data collected
by the SRA.
If you have any questions or need assistance connecting your hardware, contact KIC Technical Support
tech@kicmail.com.
Warranty Protection Impairment
Caution: RISK OF VIOLATION OF WARRANTY
Improper handling may limit our liability for damage to equipment and may also violate your
instrument warranty. As well improper handling or use could impair the protection provided by
the equipment.
