SRA Smart Reflow Analyzer Hardware Guide SRA-330200-000
26
Reinstall SRA Module
1. Reinsert the two (2) connectors from the main assembly into the front of the SRA module. NOTE: Be sure
to take note of orientation of connectors – A to A, B to B.
2. Position the SRA module in place inside the main assembly
and reinstall the four (4) mounting screws.
