SRA Smart Reflow Analyzer Hardware Guide SRA-330200-000
9
Choosing the Mode of Profiling
There are two modes – Datalog or Transmitter. In Datalog mode, the device records data as it moves through the
thermal process that it later will transfer to the computer through a USB cable. In Transmitter mode, the device sends
the data live, via Wi-Fi connection with the Smart Dock, and is displayed in the software wirelessly.
Datalog Mode
1. Launch Profiling Software 2G. Your Profiling
Software USB Security Dongle is required to use
all features in the software.
2. Use the communication cable to connect the SRA
to a USB port on the computer.
3. A message appears confirming the SRA is
detected.
4. From the Main screen, click on the Globe button
to display the Global Preferences screen.
