B-1
September 2004
Argonite
®
Engineered Fire Suppression System
38-KFSARG-000
APPENIDX B
ARGONITE
®
SURFACE FIRE REQUIREMENTS
Table B-1. Concentration of Argonite
®
Required
Project: Date:
Hazard: Engineer:
Type of Combustible:
Volume
________ L x ________ H = __________________ cu. ft./m
________ L x ________ H = __________________ cu. ft./m
________ L x ________ H = __________________ cu. ft./m
________ L x ________ H = __________________ cu. ft./m
Total
= __________________ cu.ft./m
Argonite Required (Refer to Tables B-3 and B-4)
________ Vol. x
________
(concentration factor)
= __________________ kg
________ kg x ________ = __________________ kg
Total Kilograms Required
=
__________________
Storage Required
________
kg
required
/ ________ kg/cyl
=
__________________ cylinders
__________________ Cylinders Main and __________________ Cylinders Reserve
Description Part Number
Usable Capacity
(kg)
80 L Cylinder Assembly
2900 PSI (200 bar)
DOT and TC Versions
38-100800-001 21.83
66.7 L Cylinder Assembly
2900 PSI (200 bar)
DOT and TC Versions
38-100667-001 18.21
15.9 L Cylinder Assembly
2900 PSI (200 bar)
DOT and TC Versions
38-100159-001 4.34
Note: All Cylinder Assemblies include a filled cylinder and valve.
Table B-2. Argonite Cylinder Assembly Information
