Kidde Fire Systems Argonite User Manual

6-28 July 2004
Argonite
®
Engineered Fire Suppression System
38-KFSARG-000
Table 6-21. Cylinder Rack Kits, Two Rows/Two Sides
Item
Number
Description
11 or 12 Cylinders
P/N 38-109842-001
13 or 14 Cylinders
P/N 38-109843-001
15 or 16 Cylinders
P/N 38-109844-001
17 or 18 Cylinders
P/N 38-109845-001
19 or 20 Cylinders
P/N 38-109846-001
21 or 22 Cylinders
P/N 38-109847-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-002 1 38-503075-003 1 38-503075-003 1 38-503075-004 1 38-503075-004 1 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001
3 3/8 in. Lockwasher 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001
4 3/8 in. - 16 HEX Nut 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001
5 U-Bolt 4 38-503079-001 4 38-503079-001 4 38-503079-001 4 38-503079-001 4 38-503079-001 4 38-503079-001
6 U-Bolt Lockwasher 8 38-503080-002 8 38-503080-002 8 38-503080-002 8 38-503080-002 8 38-503080-002 8 38-503080-002
7 Upright 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001
8 Rail 1 38-503074-002 1 38-503074-003 1 38-503074-003 1 38-503074-004 1 38-503074-004 1 38-503074-005
9 1/2 in. -13 Channel Nut 8 38-503082-001 10 38-503082-001 10 38-503082-001 12 38-503082-001 12 38-503082-001 14 38-503082-001
10 1/2 in. Lockwasher 12 38-503083-001 33 38-503083-001 33 38-503083-001 36 38-503083-001 37 38-503083-001 40 38-503083-001
11 Stud (Threaded Rod) 8 38-503084-002 10 38-503084-002 10 38-503084-002 11 38-503084-002 12 38-503084-002 13 38-503084-002
12 1/2 in. Flat Washer 13 38-503085-001 15 38-503085-001 17 38-503085-001 20 38-503085-001 21 38-503085-001 24 38-503085-001
13 1/2 in. - 13 HEX Nut 29 38-503086-001 33 38-503086-001 33 38-503086-001 36 38-503086-001 37 38-503086-001 39 38-503086-001
14 Cylinder Strap 6 38-503087-001 7 38-503087-001 8 38-503087-001 9 38-503087-001 10 38-503087-001 11 38-503087-001
15 Brace, Left Side 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001
16 Brace, Right Side 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 12 38-503090-001 12 38-503090-001 12 38-503090-001 12 38-503090-001 12 38-503090-001 12 38-503090-001
18 Manifold Mounting Bracket 4 38-503093-001 4 38-503093-001 4 38-503093-001 4 38-503093-001 4 38-503093-001 4 38-503093-001
19 Stud (Short Rod) 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001
Item
Number
Description
23 or 24 Cylinders
P/N 38-109848-001
25 or 26 Cylinders
P/N 38-109849-001
27 or 28 Cylinders
P/N 38-109850-001
29 or 30 Cylinders
P/N 38-109851-001
31 or 32 Cylinders
P/N 38-109852-001
33 or 34 Cylinders
P/N 38-109853-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-005 1 38-503075-003 1 38-503075-003 2 38-503075-003 2 38-503075-003 1 38-503075-004
2 3/8 in. - 16 in. x 1 in. HHDCS 2 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 2 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 2 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001
5 U-Bolt 4 38-503079-001 6 38-503079-001 6 38-503079-001 6 38-503079-001 6 38-503079-001 6 38-503079-001
6 U-Bolt Lockwasher 8 38-503080-002 12 38-503080-002 12 38-503080-002 12 38-503080-002 12 38-503080-002 12 38-503080-002
7 Upright 2 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001
8 Rail 2 38-503074-005 1 38-503074-003 1 38-503074-003 2 38-503074-003 2 38-503074-003 1 38-503074-004
9 1/2 in. -13 Channel Nut 14 38-503082-001 20 38-503082-001 20 38-503082-001 22 38-503082-001 22 38-503082-001 24 38-503082-001
10 1/2 in. Lockwasher 39 38-503083-001 51 38-503083-001 57 38-503083-001 60 38-503083-001 59 38-503083-001 63 38-503083-001
11 Stud (Threaded Rod) 14 38-503084-002 15 38-503084-002 16 38-503084-002 17 38-503084-002 18 38-503084-002 19 38-503084-002
12 1/2 in. Flat Washer 22 38-503085-001 28 38-503085-001 29 38-503085-001 32 38-503085-001 33 38-503085-001 35 38-503085-001
13 1/2 in. - 13 HEX Nut 39 38-503086-001 51 38-503086-001 53 38-503086-001 55 38-503086-001 57 38-503086-001 58 38-503086-001
14 Cylinder Strap 12 38-503087-001 13 38-503087-001 14 38-503087-001 15 38-503087-001 16 38-503087-001 17 38-503087-001
15 Brace, Left Side 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001
16 Brace, Right Side 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 12 38-503090-001 16 38-503090-001 22 38-503090-001 23 38-503090-001 22 38-503090-001 23 38-503090-001
18 Manifold Mounting Bracket 4 38-503093-001 6 38-503093-001 6 38-503093-001 6 38-503093-001 6 38-503093-001 6 38-503093-001
19 1/2 in. -13 x 1½" HHDCS –
–
2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001
20 Rail Support – – 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001
21 Rail – – 1 38-503074-002 1 38-503074-002 – – – – 1 38-503074-003
22 Header – – 1 38-503075-002 1 38-503075-002 – – – – 1 38-503075-003
23 Stud 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001
