6-29
July 2004
Argonite
®
Engineered Fire Suppression System
38-KFSARG-000
Item
Number
Description
35 or 36 Cylinders
P/N 38-109854-001
37 or 38 Cylinders
P/N 38-109855-001
39 or 40 Cylinders
P/N 38-109856-001
41 or 42 Cylinders
P/N 38-109857-001
43 or 44 Cylinders
P/N 38-109858-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-004 2 38-503075-004 2 38-503075-004 1 38-503075-005 1 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001
5 U-Bolt 6 38-503079-001 6 38-503079-001 6 38-503079-001 6 38-503079-001 6 38-503079-001
6 U-Bolt Lockwasher 12 38-503080-002 12 38-503080-002 12 38-503080-002 12 38-503080-002 12 38-503080-002
7 Upright 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001
8 Rail 1 38-503074-004 2 38-503074-004 2 38-503074-004 2 38-503074-005 1 38-503074-005
9 1/2 in. -13 Channel Nut 24 38-503082-001 26 38-503082-001 26 38-503082-001 28 38-503082-001 28 38-503082-001
10 1/2 in. Lockwasher 64 38-503083-001 67 38-503083-001 68 38-503083-001 71 38-503083-001 72 38-503083-001
11 Stud (Threaded Rod) 20 38-503084-002 21 38-503084-002 22 38-503084-002 23 38-503084-002 24 38-503084-002
12 1/2 in. Flat Washer 36 38-503085-001 39 38-503085-001 40 38-503085-001 43 38-503085-001 44 38-503085-001
13 1/2 in. - 13 HEX Nut 60 38-503086-001 62 38-503086-001 64 38-503086-001 68 38-503086-001 68 38-503086-001
14 Cylinder Strap 18 38-503087-001 19 38-503087-001 20 38-503087-001 21 38-503087-001 22 38-503087-001
15 Brace, Left Side 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001 2 38-503088-001
16 Brace, Right Side 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001 2 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 22 38-503090-001 23 38-503090-001 22 38-503090-001 23 38-503090-001 22 38-503090-001
18 Manifold Mounting Bracket 6 38-503093-001 6 38-503093-001 6 38-503093-001 6 38-503093-001 6 38-503093-001
19 1/2 in. -13 x 1½" HHDCS 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001
20 Rail Support 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001
21 Rail 1 38-503074-003 – – – – 1 38-503074-004 1 38-503074-004
22 Header 1 38-503075-003 – – – – 1 38-503075-004 1 38-503075-004
23 Stud 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001
Item
Number
Description
45 or 46 Cylinders
P/N 38-109859-001
47 or 48 Cylinders
P/N 38-109860-001
Qty. Part Number Qty. Part Number
1 Header 2 38-503075-005 2 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 4 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 4 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 4 38-503078-001 4 38-503078-001
5 U-Bolt 6 38-503079-001 6 38-503079-001
6 U-Bolt Lockwasher 12 38-503080-002 12 38-503080-002
7 Upright 4 38-503081-001 4 38-503081-001
8 Rail 2 38-503074-005 2 38-503074-005
9 1/2 in. -13 Channel Nut 30 38-503082-001 30 38-503082-001
10 1/2 in. Lockwasher 75 38-503083-001 76 38-503083-001
11 Stud (Threaded Rod) 25 38-503084-002 26 38-503084-002
12 1/2 in. Flat Washer 47 38-503085-001 48 38-503085-001
13 1/2 in. - 13 HEX Nut 70 38-503086-001 72 38-503086-001
14 Cylinder Strap 23 38-503087-001 24 38-503087-001
15 Brace, Left Side 2 38-503088-001 2 38-503088-001
16 Brace, Right Side 2 38-503089-001 2 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 23 38-503090-001 22 38-503090-001
18 Manifold Mounting Bracket 6 38-503093-001 6 38-503093-001
19 1/2 in. -13 x 1½" HHDCS 2 38-503091-001 2 38-503091-001
20 Rail Support 2 38-503092-001 2 38-503092-001
21Rail ––––
22 Header ––––
23 Stud 1 38-503084-001 1 38-503084-001
Table 6-21. Cylinder Rack Kits, Two Rows/Two Sides (cont.)
