10-6 TOS5051A/5050A
Signal Output
8
The ratings of the open-collector signal are 4.5 V to 30 VDC, 400 mA (maxi-
mum, in total). The above open-collector output circuits are isolated from other
internal circuits. except that the common lines of the output circuits are directly
connected to those of the signal input circuits. The common lines of all open-
collector circuits are connected together. The ratings are 30 VDC, 30 VACrms
MAX.
9
Loudness of the buzzer for PASS/FAIL annunciations can be controlled with the
buzzer control. It is in common for both PASS and FAIL annunciations--it does
not control them separately.
10
The rating of the 100-VAC output signal is 0.3 A (maximum).
Signal Name Conditions for Signal Generation Description
H.V ON
During the test time (period the tester delivers
the test voltage)
Open-collector signal
8
, DANGER lamp
TEST During the test
Open-collector signal
8
,
Vacuum Fluorescent Display
PASS
For PASS judgment. Delivered for approxi-
mately 0.2 s.
Open-collector signal
8
,
Vacuum Fluorescent Display, buzzer
9
U FAIL
For U FAIL judgment (detected current is
larger than upper cutoff current)
Open-collector signal
8
, Vacuum Fluorescent
Display, buzzer
9
L FAIL
For L FAIL judgment (detected current is less
than lower cutoff current)
Open-collector signal
8
, Vacuum Fluorescent
Display, buzzer
9
READY When the tester is ready to execute the test
Open-collector signal
8
,
Vacuum Fluorescent Display
PROTECTION
When the tester is in the PROTECTION
status
Open-collector signal
8
,
Vacuum Fluorescent Display
STATUS OUTPUT When one of the DIP switches for the follow-
ing items is set to ON and the corresponding
status has occurred. If two or more items are
set to ON, the signal is delivered on the logi-
cal sum of such items.
1: H.V ON
2: TEST
3: PASS
4: U FAIL
5: L FAIL
6: READY
7: PROTECTION
8: POWER ON
100 VAC
10
(even when the AC line voltage is other than
100 V)
To Next Page
