11. Functions recap
Code Description Available settings
401 Relays security 0 (negative) or 1 (positive)
402 0=>inactive
1=> setpoint 1, setpoint 2 and time-delay
2=>
3=>
403
404
400 Audible alarm 0 or 1
Channel selection for alarm 1
setpoint 1, time-delay and rising action
setpoint 1, time-delay, and falling action
Setpoint 1 of alarm 1
Setpoint 2 of alarm 1
405 Time-delay on alarm 1 from 0 to 60 seconds
406 Channel selection for alarm 2 0=>inactive
1=> setpoint 1, setpoint 2 and time-delay
2=> setpoint 1, time-delay and rising action
3=> setpoint 1, time-delay and falling action
407 Setpoint 1 of alarm 2
408 Setpoint 2 of alarm 2
409 Time-delay on alarm 2 from 0 to 60 seconds
410 Alarm type selection for Relay 1 0=> inactive
1=> setpoint 1, setpoint 2 and time-delay
2=> setpoint 1, time-delay and rising action
3=> setpoint 1, time-delay and falling action
411 Setpoint 1 of Relay 1
412 Setpoint 2 of Relay 1
413 Time-delay on Relay 1 from 0 to 60 seconds
414 Alarm type selection for Relay 2 0=> inactive
1=> setpoint 1, setpoint 2 and time-delay
2=> setpoint 1, time-delay and rising action
3=> setpoint 1, time-delay and falling action
415 Setpoint 1 of Relay 2
416 Setpoint 2 of Relay 2
417 Time-delay on Relay 2 from 0 to 60 seconds
800
802
804
806
808
810
812
814
816
818
820
822
824
826
828
830
832
834
d
b
u
o
s
M
xxx
ALARM 1ALARM 2RELAY 1RELAY 2
Page 26
CPE 300 transmitter configuration via remote control / Modbus
