1. Prerequisite
The Class 300 can output either a voltage or a current signal.
Voltage or Current ?
Down
4-20 mA
Up
0-10 V
1.b - Output signal selection
With the on-off switch located on the
left top of the transmitter (when
open), you can choose analogue
output 0-10V (voltage) or 4-20
mA (current)
CPE 300 transmitter configuration via remote control / Modbus
