Kimo CPE 300 - C- Modification of Modbus Communication Speed; D -Purge Mode

Page 22
9. Other functions
9.c- Modification of Modbus communication speed
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “100” and validate with .
Select the sub-folder “104” and validate with .
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 100.
d
b
u
o
s
M
208
With and keys, select a communication speed
(see chart below). Validate with .
00 2400 bauds 03 19200 bauds
01 4800 bauds 04 38400 bauds
02 9600 bauds 05 115200 bauds
(speed by default)
1
Step
2
Step
3
Step
4
Step
CPE 300 transmitter configuration via remote control / Modbus
1
Step
2
Step
3
Step
4
Step
9.d- Purge mode
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “300” and validate with .
Select the sub-folder “306” and validate with .
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, choose another sub-folder from the folder 300
d
b
u
o
s
M
612
With and keys, activate (01 ) or deactivate (00 ) the purge
mode. Validate with .
The purge mode enables to freeze the measurement when being displayed, enables to lock the analogue outputs,
and to activate the relay 1, in order to actuate a de-dust system of a air movement conditions.
9.d.1 -Activation / deactivation of Purge Mode
