Kimo CPE 300 - Display Configuration • F100; A - Transmitter Channel for Infrared Remote Control; B - Slave Addressing (Modbus)

4. Display configuration
4.a - Transmitter channel for infrared remote control
You can change the channel number for receiving the signal from the infrared remote control.
1
Step
Go into the configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
2
Step
Select the folder “100” and validate with .
Select the sub-folder “100” and validate with .
The cursor > goes to the line of available choices.
3
Step
With and keys, select the channel number (from 00 to 09). Validate with
.
4
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode
• press once to select another folder.
• with and keys, you can choose another sub-folder from the folder
d
b
u
o
s
M
200
By default, the channel number is 0.
Page 6
4.b - Slave addressing (Modbus)
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “100” and validate with .
Select the sub-folder “103” and validate with .
The cursor > goes to available choices.
With and keys, set the slave addressing number (from 1 to 255).
Validate with .
The cursor > goes to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys to choose another sub-folder from the folder 100.
d
b
u
o
s
M
206
1
Step
2
Step
3
Step
4
Step
CPE 300 transmitter configuration via remote control / Modbus
