7.Start and record datasets
The instrument in on.
➢ Select with arrows keys “Measurement” menu.
➢ Press OK.
➢ Select with arrows keys the measurement in which the dataset will be performed.
➢ Press “Functions” key then select “Dataset” with arrow keys and press OK.
Dataset menu is displayed.
➢ Go to line “Name” with arrow keys and press OK.
A keypad is displayed on the bottom of the screen.
➢ Select the letters with arrow keys then press OK.
To go from the lower case keypad to the upper case keypad then to the numeric keypad : press the function key :
To delete a letter press the function key “Delete”.
➢ Press the function “Validate” to validate the name of the dataset.
➢
➢ A dataset is composed of several dated measuring points. You can choose between an automatic dataset or a
manual dataset.
➢ Go to “Type” with arrow keys then press OK.
➢ Select “Manu.” for manual or “Auto.” for automatic.
➢ Go to “Start” then press OK.
7.1 Start and record datasets
7.1.1 Manual dataset
A manual dataset is composed of measuring points selected by the operator.
Manual mode is selected, measurements are displayed.
➢ Press OK to validate a measuring point.
➢ Press OK as many time as the required number of points.
➢ Press the function key “Save”.
The instrument displays the measuring dataset : type of dataset, number of points, date, minimum, maximum,
average and standard deviation.
The dataset is automatically recorded.
➢ Press OK to display the graph of the results.
➢ Press the function key “Zoom+” to display the detail of the calculated points.
➢ Press Esc key to back to the dataset screen.
➢ Press the function key “Print” to print the dataset.
Printing mode is displayed.
➢ Go to the line “Channels info” and press OK to print the channels on the printing ticket.
➢ Go to the line “Details” and press OK to print details of the dataset on the printing ticket.
➢ Press the function key “Validate” to print.
The instrument backs to the dataset display.
➢ Press Esc to back to “measurement” menu.
7.1.2 Automatic dataset
An automatic dataset is composed of measuring points with interval of time.
Automatic mode is selected, measurements are displayed.
➢ Press the function key “Duration” to set the dataset duration.
➢ Press OK on the line “Duration”.
➢ Go to “Hour” with the arrow keys then press OK, set the duration with arrow keys then press OK.
➢ Perform the same procedure for the minutes and seconds.
