➢ Select the letters with arrow keys then press OK.
To go from the lower case keypad to the upper case keypad then to the numeric keypad : press the function key :
To delete a letter press the function key “Delete”.
➢ Press the function key “Validate” to validate the name.
The recap of the Point/Point average is displayed.
➢ Press OK to display the graph.
➢ Press the function key “Zoom+” to display the detail of the calculated points.
➢ Press Esc key to back to the dataset screen.
➢ Press the function key “Print” to print the dataset.
Printing mode is displayed.
➢ Go to the line “Channels info” and press OK to print the channels on the printing ticket.
➢ Go to the line “Details” and press OK to print details of the dataset on the printing ticket.
➢ Press the function key “Validate” to print.
The instrument backs to the Point/point average display.
➢ Press Esc to back to “Measurement” menu.
7.2.2 Automatic average
This function allows to calculate an average value that the device measured in an interval chosen time.
➢ Go to “Automatic” line in the “Averages” menu and press OK.
➢ Press the function key “Start” to start the measurement.
Duration is displayed.
➢ Press the function key “Stop” to stop the measurements.
Measurements, average, minimum and maximum values, standard deviation and duration are displayed.
➢ Press the function key “Start” to launch a new automatic average.
➢ Press the function key “Save” to save the results.
A keypad is displayed on the bottom of the screen.
➢ Select the letters with arrow keys then press OK.
To go from the lower case keypad to the upper case keypad then to the numeric keypad : press the function key :
To delete a letter press the function key “Delete”.
➢ Press the function key “Validate” to validate the name.
The recap of the automatic average is displayed..
➢ Press OK to display the graph.
➢ Press the function key “Zoom+” to display the detail of the calculated points.
➢ Press Esc key to back to the dataset screen.
➢ Press the function key “Print” to print the dataset.
Printing mode is displayed.
➢ Go to the line “Channels info” and press OK to print the channels on the printing ticket.
➢ Go to the line “Details” and press OK to print details of the dataset on the printing ticket.
➢ Press the function key “Validate” to print.
The instrument backs to the automatic average display.
➢ Press Esc to back to “Measurement” menu.
7.2.3 Automatic Point/Point average
This function allows to calculate the average value of various points, calculated themselves on a duration beforehand
defined.
➢ Go to “Auto Pt/Pt” line in the “Averages” menu and press OK.
A duration is displayed on the bottom right of the screen.
➢ Press the function key “Duration” to modify the duration if necessary.
➢ Go to “min” with the arrow keys then press OK, set the duration with arrow keys then press OK.
➢ Perform the same procedure for the seconds.
20 Start and record datasets
