➢ Press the function key “Validate” when the duration is set.
➢ Press OK on the line “Interval”.
➢ Go to “min” with the arrow keys then press OK, set the duration with arrow keys then press OK.
➢ Perform the same procedure for the seconds.
➢ Press the function key “Validate” when the interval is set.
➢ Press Esc to back to measuring dataset.
➢ Press the function key “Start” to launch the measuring dataset.
The countdown starts.
• It is possible to stop the measuring dataset by pressing the function key “Stop”.
• Press “Start” to restart the dataset.
• Press “Duration” to modify the duration.
• Press “Save” to save the dataset.
The instrument displays the measuring dataset : type of dataset, number of points, date, minimum, maximum,
average and standard deviation.
The dataset is automatically recorded.
➢ Press OK to display the graph of the results.
➢ Press the function key “Zoom+” to display the detail of the calculated points.
➢ Press Esc key to back to the dataset screen.
➢ Press the function key “Print” to print the dataset.
Printing mode is displayed.
➢ Go to the line “Channels info” and press OK to print the channels on the printing ticket.
➢ Go to the line “Details” and press OK to print details of the dataset on the printing ticket.
➢ Press the function key “Validate” to print.
The instrument backs to the dataset display.
➢ Press Esc to back to “Measurement” menu.
7.1.3 View the recorded datasets
➢ Go to the “Dataset” menu with the arrow keys from the home screen.
The different measuring datasets are displayed. They are listed by date.
➢ To delete all the datasets : press the function key “Del all”.
➢ To delete just one dataset : go to the dataset to delete with the arrow keys and press the function key “Delete”.
➢ A confirmation window opens : select YES to confirm the deletion or NO to cancel.
7.2 Launch and save averages
The instrument is on.
➢ Go to “Measurement” with the arrow keys.
➢ Press OK.
➢ Press the function key “Functions” then select “Averages” then press OK.
“Average” menu is displayed.
7.2.1 Point/Point average
This function allows to calculate the average value of various points that you can select.
➢ Go to “Point/Point” line in the “Averages” menu and press OK.
➢ Press OK to add measuring points.
The instrument displays the type of dataset, number of points, date, minimum, maximum, average and standard
deviation.
➢ Press the function key “Details” to get details for each point.
➢ Press the function key “Save” to save the Point/Point average.
A keypad is displayed on the bottom of the screen.
Start and record datasets 19
