Pressure module :
• Wire probes with SMART-2014 system
Wire probes with SMART 2014 system are automatically recognized when connected to the instrument.
• Wireless probe / instrument communication
Wireless communication between probe and instrument with automatic recognition after power-up.
Wireless probes shall be located near the instrument for initial recognition. Connection between HQ210
and wireless probes must be established.
Connections of the MP210 9
C2 mini-DIN
connection
C1 mini-DIN
connection
Probes are connected
on min-DIN
connectors C1 and
/ or C2 (excepted
thermocouple probes)
Overmolded mini-DIN connector
with foolproofing system. Cable
length lg. 450 mm, extension
2.4 m.
Allows to measure the differential pressure ΔP and to calculate air velocity and airflow
with a Pitot tube or Debimo blades. It also measures the thermocouple temperature
with a wired thermocouple probe ended with a male miniature connector.
