Series Pin color and defination Function
1
RED
（
VCC
）
VCC for the display
2 BLACK(GND) GND for the display
3 YELLOW(TX) Display send out the data
4 GREEN(RX) Display receive the data
5 BLUE(K) The power cable to thecontroller
11.Version changes
The instruction manual of this instrument is the operation manual of the general software version
(version 1.0) of Tianjin King-Meter Technology Co., Ltd. The version of the instrument software used
on some vehicles may be slightly different from this manual, and
the actual version used shall prevail.
