3. Installation Instruction
Fix the display on the handlebar, adjust the angel. Connect the two plugs from display and
controller when it is off power supply.
4. Standard Operation
4.1 Power ON / OFF
Hold on “MODE” for 1second to start display and supply power to the controller, When at
working state, hold on ”MODE” for 2.5 seconds to shut off E-bike power.
Display does not use the power in shutdown.Leak of current will be less than 1uA
If the E-bike doesn’t use more than 10 minutes, display will turn off automatically.
4.2 User interface
Power on the display and showing as following interface:
