King-Meter KM3209 - Monitor Area; Button Definition

KING-METER TECHNOLOGY CO., LT
No.15, Chenchang Road, Beichen Dist.Tianjin,300134,CN
Fax
：
+0086 022 8478 0358 Tel: +0086 022 8478 0378
3
◆
Multiple parameter setting
◆
Mobile phone charging (only for instruments with USB interface)
◆
SuppoRt the ADST function(detailed information following the <ADST updated too(standard
version)> instruction )
◆
The communication between the display and the controller is following the <ANADA’s
EN13849:2017 protocol V11.0_1.3.4>, and above version. (Following the ANANDA’s newest version
and compatible with the old version.)
2.2 Monitor Area
KM3209 LED NORMAL DISPLAY INTERFACE
2.3 Button Definition
Insubsequent instructions, b
utton
is replaced by “MODE”. Button
“+”
is replaced
by“UP”, button - is replaced by“DOWN”.
SPEED TRIP ODO
UP
DOWN
Power ON /OFF
Battery
Indicator
