LOGC31 Placement Guidelines for Model MDV31/39
Photo 1 Photo 2
Step (1) Place notch area of Log #1 up against pilot assembly. Step (2) Place flat area of Log #2 up against Tab 2a and rest short
branch onto second grate bar.
Step (3) Locate mounting hole, bottom of Log #3 onto Tab 3a and have
char area touch Tab 3b.
TAB 3a TAB 3b TAB 4a
TAB 4b
TAB 2a
GRATE
BAR
EMBER
PLATES
❷
❶
❸
❹
❺
❻
❼
EMBERS
ROCK
FLAT
AREA
NOTCH
NOTCH
❶
❷
GRATE
BAR
TAB 2a
TAB 3b
❸
