Chapter 1 Before Use 1-5
1. 4 Specifications
1. 4. 1 General
Subject Specification
Model KIP 3100
Configuration Console
Power consumption
(Maximum)
1,440W (Including Scanner & Controller Unit)
Power consumption
(Low power mode)
43.6W
Acoustic noise Idling Max. 60db
Printing Max. 65db
Impulse sound Max. 70db EN ISO 7779
Ozone Max. 0.05ppm (Measurement method under UL Standard)
Dimensions 1266mm (Width) x 600mm (Depth) x 1107mm (Height)
(UI is not included)
Weight About 485lbs (219kg) (1 roll)
About 511lbs (232kg) (2 roll)
Environmental condition
for usage
(Temperature)
50 to 89.6 F (10 to 32 degrees Centigrade)
(Humidity)
15 to 85% RH
Interface Network Interface (10 BASE-T / 100 BASE-TX)
Input power In the US : 120V plus/minus 10%, 50/60Hz, 12A
In Europe : 220-240V plus 6% or minus 10%, 50/60Hz, 7A
NOTE
The above specifications are subject to change without notice.
