Chapter 3 Error Correction 3-3
3. 1. 1. 1 Deck Jam / Feeding Jam
Either of “Deck is jam” or “Feeding Jam” will be indicated when the roll paper is mis-fed in the Roll
Deck.
1. Open the Roll Deck, and then rewind the roll paper.
2. Insert the leading edge of roll paper under the Guide Plate (1) until the edge touches the
feeding roller.
Then rotate the Paper Feeding Knob (2) clockwise so that the feeding rollers catch the roll
paper.
2
5
NOTE
The leading edge should be trimmed with a cutter
in case of an extreme crease.
For Roll 2, use the Paper Feeding Knob on the
rear side (3).
3
1
