KIP 3100 - 3.1.1.3 Registration;Internal Jam

Chapter 3 Error Correction 3-6
3. 1. 1. 3 Reg. Jam / Internal Jam
1. Pull up the Engine Unit Open Levers (1) to open the Engine Unit.
2. Remove the mis-fed paper.
3. Close the Engine Unit firmly.
NOTE
Be sure to close the Engine Unit firmly until it is locked at the correct position.
NOTE
Do not open the Engine Unit when the Scanner Unit is opened.
If the Scanner Unit is o
p
ened
,
it will hit the bottom of User Interface.
1
