Chapter 3 Error Correction 3-20
5. Move the Cutter Knob (8) to the other end, in order to manually cut the media.
6. Carefully pull and remove the jammed sheet (9) from the rear.
8
8
9
WARNING
(1) There are extremely hot parts inside the Fuser Unit. Do not touch any parts in the Fuser
Unit, or you will be burnt.
Also the mis-fed media can be very hot. Be careful not to get burnt when you remove it.
(2) The stripping claws (10) with a sharp edge are on the inside face of the Fuser Cover.
Take care not to get scratched on them when removing a sheet.
10
10
10
To Next Page
