Kirisun DP480 Service Manual

DP480 Service Manual
56
98
1TT1-2SC5108-Y
R SMD transistor
TOSHIBA,2SC5108-Y,2-2H1A,-
~125℃
1
Q502
99
1TT1-L2SC3356LT1
SMD transistor
LRC,L2SC3356LT1,SOT-23,-
~150℃
1
Q503
100
2RS1-16-333J
R Chip resistor
yageo,RC0603JR-0733KL,33,KΩ,
±5%,1608
1
R8
101
2RS1-16-103J
R Chip resistor
yageo,RC0603JR-0710KL,10,KΩ,
±5%,1608
1
R12
102
2RS1-10-472J
R Chip resistor
yageo,RC0402JR-074K7L,4.7,KΩ,
±5%,0402
3
R39,R561,R562
103
2RE1-16-2203
SMD precision resistor
yageo,RC0603FR-07220KL,220,K
Ω,±1%,0603
1
R42
104
2RS1-10-470J
R Chip resistor
yageo,RC0402JR-0747RL,47,Ω,±
5%,0402
1
R500
105
2RS1-10-682J
R Chip resistor
yageo,RC0402JR-076K8L,6.8,KΩ,
±5%,1005
1
R503
106
2CC1-10-C0G500-
150J
R Multi-layer chip capacitor
MURATA,GRM1555C1H150JA01D
,15,pF,±5%,50V,0402,C0G
1
R504
107
2RS1-16-271J
R Chip resistor
yageo,RC0603JR-07270RL,270,Ω,
±5%,1608
2
R505,R515
108
2RS1-10-152J
R Chip resistor
yageo,RC0402JR-071K5L,1.5,KΩ,
±5%,0402
2
R507,R51
109
2RS1-10-563J
R Chip resistor
yageo,RC0402JR-0756KL,56,KΩ,
±5%,0402
2
R509,R38
110
2RS1-10-330J
R Chip resistor
yageo,RC0402JR-0733RL,33,Ω,±
5%,0402
1
R510
