Kirisun DP580 - Page 53

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
36 2RS1-10-000O R chip resistor 1005, 0Ω 55
C480,R170,R171,R173,R311,R313,R308,R34,R61,R140,R14
2,R80,R137,R220,C358,R169,FB21,FB22,FB23,R157,R179,
R183,R184,R185,FB24,FB25,FB26,FB27,R186,R187,R281,R
282,R283,R284,FB28,FB29,FB30,FB31,FB32,FB33,FB34,FB
35,FB36,FB37,R22,R152,R232,R233,R234,R235,R257,R274
,R275,R276,R300
37
2CC1-10-Y5V160-10
5Z
Multi-layer chip capacitor 1005, 1uF+80%/-20%, 16V, Y5V 26
C482,C483,C486,C488,C489,C493,C495,C496,C350,C351,C
363,C364,C365,C366,C367,C306,C413,C414,C416,C542,C4
84,C490,C497,C504,C401,C463
38 1IS1-XC6209F332M SMD voltage regulator IC
3.3V, SOT-23-5 encapsulation,
300mA, XC6209F332MR
2 IC15,IC8
39 2LL1-16-3N9SA Multi-layer chip inductor
1608, 3.9nH±0.3nH
(SDCL1608C3N9STDF),
SunLord
2 L2,L3
40 2LL1-16-10NJA Multi-layer chip inductor
1608, 10nH±5%
(SDCL1608C10NJTDF),
SunLord
2 L4,L42
41 2LL1-16-8N2DA Multi-layer chip inductor
1608, 8.2nH±0.5nH
(SDCL1608C8N2JTDF),
SunLord
1 L6
42 2RS1-10-473J R chip resistor 1005, 47K±5% 16
R12,R18,R52,R98,R119,R123,R226,R227,R153,R302,R317,
R318,R319,R320,R321,R322
43 1IS1-AT2659 Low-noise amplifier
AT2659, 1550 MHz~1615 MHz,
6-pin DFN, ICOFCHINA
1 U2
44
1IS1-UBX-M8030
GPS IC
GPS chip, UBX-M8030, UBLOX
1
U3
