Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
45
5OT1-26R0-DSB221
SDN
SMD temperature
compensated crystal
oscillator
26MHz±0.5ppm, -30℃~+85℃,
1.8V, 2.5*2.0, lead free
1 X101
46
5XT1-TFX02S-32R76
8
SMD ceramic resonator
32.768KHZ, TFX-02S, 7PF,
3215, 20PPM, lead free
1 Y1
47
5FT1-LFB212G45CG
1C18
SMD ceramic filter Bluetooth filter 1 F2
48 1IM1-CSR8670C Bluetooth chip
CSR8670C-IBBH-R,
VFBGA112-BALL encapsulation
1 IC16
49 3CR1-MM9329-2700 RF coaxial cable
MM9329-2700, Mutata,
-40
℃
~90
℃
1 J8
50 2RS1-10-330J R chip resistor 1005, 33Ω±5% 25
R285,R286,R287,R288,R289,R290,R76,R164,R165,R166,R1
67,R168,R148,R149,R150,R151,R188,R189,R191,R207,R20
8,R209,R236,R237,R238
51
2RS1-10-152J
R chip resistor
1005, 1.5K±5%
2
R310,R99
52 5XC1-26R0-3225 Crystal resonator
26MHz, ±20PPm, 3225
encapsulation
1 X1
53
2CC1-10-C0G500-10
1J
R multi-layer chip
capacitor
1005, 100P±5%, 50V, C0G 22
C86,C89,C116,C131,C138,C380,C335,C336,C341,C342,C34
3,C344,C345,C347,C353,C354,C394,C395,C397,C400,C429
,C430
54
2CC1-10-X7R500-33
2K
R multi-layer chip
capacitor
1005, 3300P±10%, 50V, X7R 2 C109,C160
55
2CC1-32-X7R251-47
3K
Multi-layer chip capacitor
3216, 47nF±10%, 250V, X7R,
GRM31CR7272E473K
1 C112
56
2CT1-TS32-160-3R3
M
R SMD Tantalum capacitor
3216, 3.3μF±20%, 16V, TS
series (Encapsulation A)
1 C113
51
