Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
70
2CC1-10-C0G500-18
0J
R multi-layer chip
capacitor
1005, 18P±5%, 50V, C0G 3 C164,C169,C194
71
2CC1-10-C0G500-27
1J
Multi-layer chip capacitor 1005, 270P±5%, 50V, C0G 4 C165,C166,C222,C227
72
2CC1-10-C0G500-30
0J
Multi-layer chip capacitor 1005, 30P±5%, 50V, C0G 5 C168,C170,C265,C266,C289
73
2CT1-TP20-100-2R2
M
R SMD Tantalum capacitor
2012, 2.2μF±20%, 10V, TP
series (Encapsulation P)
1 C402
74 1DV1-1SV305 R SMD varactor 1SV305 14 D4,D5,D6,D7,D8,D9,D10,D11,D13,D18,D19,D21,D22,D29
75
1DS1-DA2S10100L
R SMD switch diode
DA2S10100L
1
D12
76 1IS1-LMX2571NJKT Phase-locked loop IC
Texas Instruments, model
LMX2571NJKT, 36-pin WQFN
encapsulation
1 IC7
77 1TC1-UMC4 R SMD Darlington tube
UMC4, NPN/PNP Darlington
tube
2 IC10,IC14
78 1IS1-OPA348 Operational amplifier IC
Model OPA348, SC70-5
encapsulation
2 IC11,IC12
79 2LW1-25UC-471K
R SMD wire wound
inductor
2520, 0.47μH±10%, ceramic
core (FLM2520-R47K)
1 L8
80 2LW1-16UC-R33G SMD wire wound inductor
1608, 330nH±2%
(C1608BR33G), lead free
15
L9,L12,L13,L14,L18,L19,L20,L23,L24,L26,L50,L51,L56,L57,L
59
81 2LW1-20UC-150J SMD wire wound inductor
2012, 15nH±5%, ceramic core
(C2012C-15NJ)
1 L10
82 2LW1-20UC-8R2J SMD wire wound inductor
2012, 8.2nH±5%, ceramic core
(C2012C-8N2J)
2 L11,L66
53
