Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
83 2LW1-16UC-181J SMD wire wound inductor
1608, 180nH±5%, ceramic core
(C1608CB-R18J)
2 L15,L47
84 2LW1-20UC-390GA
R SMD wire wound
inductor
2012, 39nH±2%, ceramic core
(C2012C-39NG)
1 L16
85 2LW1-20UC-120GA SMD wire wound inductor
2012 (0805) 12nH±2%, sagami,
ceramic core
1 L17
86 2LW1-16UC-120G SMD wire wound inductor
1608, 12nH±2%, ceramic core
(C1608CB-12NG)
4 L21,L32,L58,L60
87 2LL1-16-4R7KA Multi-layer chip inductor
1608, 4.7μH±10%
(SDFL1608Q4R7KTFB01),
SunLord
1 L22
88 2LL1-16-1R0KB Multi-layer chip inductor
1608, 1μH±10%
(SDFL1608Q1R0KTFB02),
SunLord
2 L25,L54
89 2LL1-16-22NJB Multi-layer chip inductor
1608, 22nH±5%
(SDCL1608C22NJTDF),
SunLord
3 L27,L29,L31
90 1TT1-L2SC3356LT1 SMD triode L2SC3356LT1, SOT23, NPN 4 Q3,Q104,Q8,Q9
91
1TT1-2SC4617-R
R SMD triode
2SC4617-R(BR), EMT3
1
Q4
92
1TT1-SSM3J15FS
Switch triode
SSM3J15FS, PMOS
1
Q5
93 1TT1-2SC5086 SMD triode
Tube power amplifier,
2SC5086-O
4 Q6,Q7,Q13,Q14
94 2RS1-10-101J R chip resistor 1005, 100Ω±5% 9 R24,R25,R26,R27,R41,R45,R49,R62,R66
95 2RS1-10-6R8J Chip resistor 1005, 6.8Ω±5% 3 R30,R31,R33
96
2RS1-10-332J
R chip resistor
1005, 3.3K±5%
1
R35
97
2RS1-10-121J
R chip resistor
1005, 120Ω±5%
3
R36,R40,R44
54
