Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
98
2RS1-10-120J
Chip resistor
1005, 12Ω±5%
1
R37
99
2RS1-10-822J
R chip resistor
1005, 8.2K±5%
3
R42,R55,R202
100
2RS1-10-392J
R chip resistor
1005, 3.9K±5%
5
R43,R46,R48,R56,R108
101 2RS1-10-562J R chip resistor 1005, 5.6K±5% 1 R47
102 2RS1-10-123J R chip resistor 1005, 12K±5% 2 R53,R100
103 2RS1-10-273J R chip resistor 1005, 27K±5% 1 R54
104 2RS1-10-224J R chip resistor 1005, 220K±5% 2 R60,R161
105 2RS1-10-124J R chip resistor 1005, 120K±5% 2 R64,R72
106 2RS1-10-680J R chip resistor 1005, 68Ω±5% 1 R215
107 5XC1-16R8-6800CFA Crystal oscillator
1XTV16800CFA, 16.8MHz, 3225
encapsulation, VC-TCXO, KDS
1 U9
108
2CC1-10-C0G500-4R
0C
R multi-layer chip
capacitor
1005, 4P±0.25P, 50V, C0G 5 C174,C246,C256,C300,C473
109
2CC1-10-C0G500-12
0J
R multi-layer chip
capacitor
1005, 12P±5%, 50V, C0G 1 C184
110
2CC1-10-C0G500-10
0J
Multi-layer chip capacitor
1005, 10P±5%, 50V, C0G,
GJM1555C1H100JB01, Murata,
HiQ
3 C190,C240,C247
111
2CC1-10-X7R160-47
3K
R multi-layer chip
capacitor
1005, 47nF±10%, 16V, X7R 1 C191
112
2CC1-10-C0G500-33
0J
R multi-layer chip
capacitor
1005, 33P±5%, 50V, C0G 2 C193,C245
113
2CC1-16-C0G500-22
0J
R multi-layer chip
capacitor
1608, 22P±5%, 50V, C0G 1 C201
55
