Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
127
1DS1-1SS390
SMD switch diode
1SS390, 1608
4
D14,D15,D16,D17
128 5FE1-BLM21P300S R SMD EMI filter
2012,
BLM21P300S/BLM21PG300S
(0149-05)
1 FB12
129 1IL1-NJM2904V R SMD linear IC
Operational amplifiers
NJM2904V and TSSOP-8
1 IC13
130 2LL1-16-33NJA Multi-layer chip inductor
1608, 33nH±5%
(SDCL1608C33NJTDF),
SunLord
1 L28
131 2RS1-16-000O R chip resistor 1608, 0Ω 2 L30,L55
132
2LH1-R501R5-R05-0
5
SMD air core inductor
Wire diameter φ0.50, inner
diameter φ1.5, 5-wind, forward
winding
1 L33
133 2RS1-16-300J Chip resistor 1608, 30Ω±5% 1 L34
134
2LH1-R401R5-R08-0
5
R SMD air core inductor
(SC) wire diameter φ0.40, inner
diameter φ1.5, 5-wind, forward
winding
1 L36
135
2LH1-R401R5-R03-0
5
R SMD air core inductor
Wire diameter φ0.40, inner
diameter φ1.5, 3-wind, forward
winding, 0.5mm long pins
4 L37,L38,L39,L40
136
2LH1-R401R5-R04-0
5
R SMD air core inductor
Wire diameter φ0.40, inner
diameter φ1.5, 4-wind, forward
winding, 0.5mm long pins
1 L41
137 2LL1-16-R22JA Multi-layer chip inductor
1608, 0.22uH±5%, [Made in
China] (CH160808-R22J)
1 L43
138 2LW1-20UC-221J
R SMD wire wound
inductor
2012,220nH±5%, ceramic core
(LQN21AR22J/LQW2BHNR22J
1 L316
57
