Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
03L)
139
1TF1-RD01MUS2-50
1
ER SMD field effect
transistor
Mitsubishi, RD01MUS2-T513
tray package, lead free
1 Q10
140
1TF1-RD07MUS2B-5
01
ER SMD field effect
transistor
Mitsubishi, RD07MUS2B-T512
tray package, lead free
1 Q11
141
2RS1-10-390J
Chip resistor
1005, 39Ω±5%
1
R67
142 2RS1-10-151J R chip resistor 1005, 150Ω±5% 2 R68,R69
143 2RS1-10-220J R chip resistor 1005, 22Ω±5% 1 R71
144 2RS1-10-510J Chip resistor 1005, 51Ω±5% 3 R74,R102,R118
145 2RS1-10-682J R chip resistor 1005, 6.8K±5% 2 R75,R77
146 2RS1-10-100J R chip resistor 1005, 10Ω±5% 2 R79,R249
147
2RS1-16-103J
R chip resistor
1608, 10K±5%
1
R81
148
2RS1-32-R39J
R chip resistor
3216, 0.39Ω±5%
3
R82,R83,R84
149
2RE1-10-1003
Precise SMD resistor
1005, 100K±1%
4
R86,R90,R85,R87
150
2RE1-10-1004
R precise SMD resistor
1M 1005, 1M±1%
2
R88,R89
151
2RS1-10-271J
R chip resistor
1005, 270Ω±5%
1
R91
152 2RS1-10-222J R chip resistor 1005, 2.2K±5% 8 R92,R121,R125,R156,R190,R239,R240,R241
153 2RS1-10-163J R chip resistor 1005, 16K±5% 1 R93
154 2RS1-10-203J R chip resistor 1005, 20K±5% 1 R95
155 2RS1-10-823J R chip resistor 1005, 82K±5% 3 R101,R129,R304
156
2RS1-10-333J
R chip resistor
1005, 33K±5%
3
R103,R250,R251
157
2RS1-16-271J
R chip resistor
1608,270Ω±5%
1
R104
158
2CC1-10-C0G500-24
0J
R multi-layer chip
capacitor
1005, 24P±5%, 50V, C0G 5 C243,C248,C259,C263,C474
58
