Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
159
2CC1-10-C0G500-22
1J
R multi-layer chip
capacitor
1005, 220P±5%, 50V, C0G 5 C270,C274,C275,C278,C303
160
2CC1-10-X7R500-33
1K
R multi-layer chip
capacitor
1005, 330P±10%, 50V, X7R 3 C271,C65,C66
161
2CC1-10-C0G500-16
0J
Multi-layer chip capacitor 1005,16P±5%,50V,C0G 3 C284,C287,C301
162
2CC1-10-C0G500-15
0J
R multi-layer chip
capacitor
1005, 15P±5%, 50V, C0G 2 C286,C288
163
2CC1-10-C0G500-5R
6C
Multi-layer chip capacitor 1005, 5.6P±0.25P,50V,C0G 1 C291
164
2CC1-10-C0G500-4R
7C
R multi-layer chip
capacitor
1005,4.7P±0.25P,50V,C0G 1 C299
165
2CC1-10-C0G500-1R
5C
R multi-layer chip
capacitor
1005,1.5P±0.25P, 50V, C0G 1 C470
166 1DS1-RB706F-40 R SMD switch diode
Schottky barrier diode,
RB706F-40,SOT-323
1 D20
167 2LW1-20UC-220J
R SMD wire wound
inductor
2012, 22nH±5%, ceramic core
(C2012C-22NJ)
5 L44,L45,L48,L49,L67
168 2LL1-16-15NJA Multi-layer chip inductor
1608, 15nH±5%
(SDCL1608C15NJTDF),
SunLord
1 L46
169 2LI1-1608-R39G Radial choke inductor
0603, 390nH±2%, Murata.
LQW18ANR39G00
1 L52
170
2RS1-16-101J
R chip resistor
1608, 100Ω±5%
1
L53
171 2LL1-16-18NJA Multi-layer chip inductor
1608, 18nH±5%
(SDCL1608C18NJTDF),
1 L72
