Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
SunLord
172 1TT1-AT32011 Silicon bipolar transistor
Low power consumption, low
noise, NPN type, AT-32011,
SOT-143 encapsulation,
AVAGO, lead free
1 Q12
173 1TT1-2SC5108-Y R SMD triode 2SC5108-Y (MC), NPN 3 Q15,Q16,Q28
174 2RS1-10-302J R chip resistor 1005, 3K±5% 1 R110
175 2RS1-10-470J R chip resistor 1005, 47Ω±5% 2 R111,R135
176 2RS1-10-180J R chip resistor 1005, 18Ω±5% 1 R112
177
2RS1-10-301J
R chip resistor
1005, 300Ω±5%
2
R113,R114
178
2RS1-10-105J
R chip resistor
1005, 1M±5%
2
R117,R162
179
2RS1-10-363J
R chip resistor
1005, 36K±5%
2
R120,R124
180 2RS1-10-182J R chip resistor 1005, 1.8K±5% 2 R122,R126
181 2RS1-10-684J R chip resistor 1005, 680K±5% 1 R130
182 2RS1-10-393J R chip resistor 1005, 39K±5% 1 R132
183 2RS1-10-184J R chip resistor 1005, 180K±5% 1 R133
184 2RS1-10-150J R chip resistor 1005, 15Ω±5% 1 R136
185 1IS1-ADEX10L SMD mixer
Mini-Circuits, model ADEX-10L+,
lead free
1 Z1
186
5XC1-50R0-49910G
Q9
Crystal oscillator
1D49910GQ9, 49.95 MHz, 7*5,
KDS
1 Z2
187 1IM1-AK2365A FM demodulation chip
FM IF detector with narrow band
filter, model: AK2365A, 32-pin
1 IC17
188 2LL1-16-R47KB Multi-layer chip inductor
1608, 0.47μH±10%
(SDFL1608LR47KTFB04),
1 L61
60
