Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
SunLord
189
2RE1-10-4702
Precise SMD resistor
1005, 47K±1%
1
R158
190
2RS1-10-154J
R chip resistor
1005, 150K±5%
2
R159,R13
191
2RS1-10-683J
R chip resistor
1005, 68K±5%
3
R163,R7,R9
192 2RS1-10-821J R chip resistor 1005, 820Ω±5% 1 R174
193 2RS1-10-513J R chip resistor 1005, 51K±5% 1 R270
194 1IS1-LT1901A-MCU
MCU + baseband
processing IC
LT1901A, for radio S566 1 IC19
195
2RS1-10-304J
R chip resistor
1005, 300K±5%
1
R181
196
5XT1-MC146-32R76
K
E SMD ceramic resonator
32.768KHZ, MC-146, 12.5PF,
20PPM, lead free
1 X301
197 3FW1-0805L035 Fuse
0805L035 350mA, PTC,
Littlefuse
1 FB49
198
1ID1-TS3A24159DG
SR
Single-pole double-throw
analog electronic switch
TS3A24159DGSR, lead free 1 IC4
199 2RS1-10-4R7J R chip resistor 1005, 4.7Ω±5% 2 R14,R15
200 2RS1-10-472J R chip resistor 1005, 4.7K±5% 1 R19
201 1IS1-TDA2822 ER SMT IC TDA2822 1 U600
202 1IS1-LTJIAMI Encryption chip LTJIAMI, for radio DP585 1 IC18
203
2RS1-10-202J
R chip resistor
1005, 2K±5%
1
R225
204
5OT1-26R0-HHL-030
3
SMD temperature
compensated crystal
oscillator
26MHz±2ppm, -30 ℃~+85 ℃,
2.8V, 3.2*2.5, Yixin brand, lead
free
1 Y3
205
2CC1-10-X7R250-22
R multi-layer chip
1005, 22nF±10%, 25V, X7R
2
C462,C465
61
