DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
3K
capacitor
206
2RS1-10-204J
R chip resistor
1005, 200K±5%
3
C464,R253,R299
207 4PE1-16-F2 R SMD light emitting diode
1608, red light,
19-21SUR/S530-A2/TR8
1 D24
208 4PE1-16-F5
R SMD light emitting diode
1608, green light,
H19-213SYGC
1 D25
209 1DR1-ESD9B5 TVS diode
ESD9B5. 0ST5G, 5V, SOD923,
lead free
7 D26,D27,D28,D32,D33,D34,D35
210 1IS1-ADS1015 A/D converter IC
ADS105IRUGT, 10-Pin, QFN
encapsulation, Texas
Instruments, lead free
1 IC2
211 1IS1-DAC104S085 D/A converter IC
DAC104S085, VSSOP
encapsulation
1 IC9
212
1DR1-TPD4S012DR
Y
TVS diode
TPD4S012DRY, 4-CHANNEL
ESD SOLUTION FOR
USB-HS/USB OTG/USB CH
1 IC21
213
1ID1-MXD2020ML
SMD universal logic IC
MXD2020ML, LCC-8, lead free
1
IC22
214
1IM1-AT24C512C
SMD memory
AT24C512C, ATMEL, lead free
1
IC23
215 3CF1-BL112-20RL
R SMD FPC/FPC
connector
Spacing 0.5mm, 20-pin,
horizontal type
1 J2
216 3CF1-BL112-30RU SMD FFC/FPC connector
Spacing 0.5mm, 30-pin,
horizontal type
1 J3
217 3ST1-SKRTLBE010 R SMD tact switch
SKRTLBE010, 4.5*3.55*3.3mm
(ALPS)
1 S1
218 1IM1-TC58CVG1S3H
SMD FLASH storage IC
TC58CVG1S3HxAIx, WSON8,
2G bits, Toshiba, lead free
1 U4
62
