Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
219
1IM1-H8ACS0PG0AB
R-A
H8ACS0PG0ABR IC
Hynix, MCP, 1Gb (128Mb x8)
NAND Flash+512Mb
(32Mb x16)
mobile SDR
1 IC20
220 6PM7-4207-HMD Main board DP586-02
DP586_MAIN_180201, 1.2mm
thick, FR-4, 106X46mm, 6-
layer,
lead free
1
221 7MDC-4207-01A-W
VCO shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 31.05*13.3*3,
Chuanghong brand, lead free
1 P1
222 7MDC-4207-02A-W
GPS shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, heteromorphic,
33*13.05*3, Chuanghong brand,
lead free
1 P2
223 7MDC-4207-03A-W
Automatic power control
(APC) shield cover
Copper-Nickel-Zinc alloy, 0.2
mm thick, square,
21.3*11.45*2.2, Chuanghong
brand, lead free
1 P3
224 7MDC-4207-04A-W
Power shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 16.2*15.1*2.3,
Chuanghong brand, lead free
2 P4,P5
225 7MDC-4207-05A-W
Amplifier shield cover
(for radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 16.3*10.95*2,
Chuanghong brand, lead free
1 P6
226 7MDC-4207-06A-W
Baseband shield cover
(for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, heteromorphic,
44*19.97*2.3, Chuanghong
brand, lead free
1 P7
